China Hot Sale MTNG400S-3 Wheel Type Mobile Crushing and Screening Station Plant Price

Name: China Hot Sale MTNG400S-3 Wheel Type Mobile Crushing and Screening Station Plant Price
Brand: Henan Hongxing Mining Machinery Co., Ltd.
Availability: InStock

Large Image : China Hot Sale MTNG400S-3 Wheel Type Mobile Crushing and Screening Station Plant Price

Product Details:

Contact Now

Detailed Product Description

The MTN series of wheel-type mobile production lines fully cover the application fields of hard rock, soft rock,and construction waste with a processing capacity of 100-300 tons per hour.

The overall appearance of the mobile station is beautiful,the workmanship is exquisite, the host is equipped with the latest technology, the performance is stable and reliable, and the output is high. A large number of belt conveyors which are assembled on the trailer eliminate the need for on-site transfer and external belt conveyors, and the work site is tidy and organized; Each mobile station is equipped with a crawler plate device to ensure that the equipment arrives at the site quickly for installation and commissioning, and reduces the concrete foundation preparation time.

Equipment Advantage

High-Performance Main Machine

The main equipment on the production line are all high- performance machines produced with the latest industry technology, with high efficiency,high output, few failures, convenient operation and maintenance,and stable and reliable operation.

Modular Design

The MTN series mobile production line adopts modular and universal design, with high structural strength and strong versatility. The equipment with the same processing capacity can achieve maximum versatility.

Humanized Maintenance Platform

The front and back connection design of the maintenance platform is convenient for the operator to observe the equipment operation in time and maintain it.Inclined up and down escalators, wider pedals, safer and more convenient than upright ladders. Some models add a small climbing ladder at the rear, which is convenient for personnel to check and maintain.

Trailer-Mounted Electronic Control System

Each device of the mobile production line is equipped with an independent electronic control system,which is easy to operate. The cables of each device have been connected before leaving the factory. There is no need to disassemble for transportation. The whole machine can be debugged quickly when it arrives on site.

Trailer-Mounted Belt Conveyor

Each equipment of the mobile production line is equipped with a vehicle mounted belt conveyor, which does not need to be disassembled during transportation and it saves the time for on-site production and installation of external belt conveyors. Work can be started quickly when arriving at the site, and the work site is clean and orderly.

Concrete Foundation Free

Each equipment of the mobile production line is equipped with an outrigger crawler device, which can save the cost and time of the concrete foundation, reduce the requirements for the foundation of the work site,and reduce the foundation investment.It is put away during transportation and transfer, and can be quickly supported when arriving at the site.

Large Volume Silo Design

Both the feeder silo of the coarse crushing equipment and the feeding belt conveyor silo of the medium crushing equipment adopt a large capacity design. Certain materials can be stored to ensure uniform and stable feeding.The large capacity silo is convenient for fee ding and can store certain materials at the same time to ensure uniform and stable feeding.

Precisely Control the Feeding Amount

The feeder adopts frequency o conversion control, and the feeding amount of the feeder can be adjusted according to different conditions to give full play to the production capacity of the production line.The feeder is equipped with a pre- screening function, which can separate finely divided materials and muck in advance and imp rove the processing capacity of the equipment.

Application fields: Wotetrack cone crusher station is widely applied in metallurgical, construction, road building, chemical and phosphatic industry.

Working Principle

Material by the feeder evenly to the jaw crusher, after beginning of jaw crusher broken material by the conveyor into the counterattack crusher for secondary crushing, crushing the material through the sieve sieve, satisfies the requirement of the broken material from the conveyor output, does not meet the requirements of the material into the counterattack crusher broken again, the caterpillar jaw crusher + reaction type mobile crushing plant production line through circular vibrating screen constitute closed-circuit system, realize the material cycle of broken, finished product material from the conveyor output, continuous crushing operations.

Technical Parameter

Series	Standard Model	On Board Equipment	On Board Equipment	Processing Capacity(t/h)	Transport Dimensions(mm)
Four Combination Mobile Station	MTN100Y-2	GZD850*3000/2YK1545	HD72/GYS300	50-100	1500026504500
		MTN100Y-3	GZDT0835/3HX1548	HDX86/SC100F1	50-100	1750025004000
		MTN150Y-3	GZDT0835/3HX1548	HDX86/SC160F1	70-150	1750025004000
		MTN-150R-3	GZDT0835/3HX1548	HDX86/CI1110	60-150	1750025004000
Mobile Coarse Crushing Station	MTN96	GZDT9538	CJ96	70-200	1300029504250
		MTN98	GZDT9538	HDX98	80-200	1300029504250
		MTN106	GZDT1145A	CJ106	90-300	1400030004400
		MTN110	GZDT1145A	HDX110	120-300	1400030004400
		MTN1213C	GZDT9538	CI1213	80-200	1300029504250
		MTN1316C	GZDT1145A	CI1316	100-300	1400030004400
Mobile Medium and Fine Crushing Station	MTN300	---	HPM300C1	100-200	1550029004200
		MTN400	---	HPM400C3	150-300	1650031004300
		MTN250	---	SC250F1	90-200	1650031004300
		MTN1213	---	CI1213	80-200	1600029004300
		MTN1316	---	CI1316	100-300	1650031004500
		MTN0926	---	HVI0926	85-200	1650031004300
		MTN1040	---	HVI1040	120-300	1650031004400
Mobile Screening Station	MTN1865-3	---	3HX1865	65-200	1450029004000
Mobile Screening Station		MTN2165-3	---	3HX2165	85-300	1500029004400
Mobile Station For Medium and Fine Crushing and Screening	MTN300S-3SII	3HX1865	HPM300C1	100-200	1500030004000
		MTN300S-3	3HX2165	HPM300C1	100-200	1500030004000
		MTN400S-3	3HX2165	HPM400C3	150-300	1500030004000
		MTNG400S-3SII	3HX1865	GYS400C1	100-200	1500030004000
		MTN400S-3	3HX2165	GYS400C1	100-200	1500030004000
		MTN250S-3	3HX2165	SC250F1	90-200	1500030004000
		MTN1213S-3	3HX1865	CI1213	80-200	1500030004200
		MTN1316S-3	3HX2165	CI1316	100-300	1500030004200
		MTN0926S-2	3HX1865	HVI0926	85-200	1800030004200
		MTN1040S-2	3HX2165	HVI1040	120-300	1800030004200
Three Combination Mobile Station	MTN1213-III	GZDT9538/3HX1865	CI1213	80-200	1820028004350
		MTN1316-III	GZDT1145A/3HX1865	CI1316	100-300	1820030004200
		MTN1410-III	GZDT9538/3HX1865	PCZ1410	80-200	1820028004200
		MTN1612-III	GZDT1145A/3HX2165	PCZ1612	100-300	1820030004200

Mobile Jaw Crushing Station

Mobile Impact Crushing Station

Mobile Cone Crushing Station

Mobile Screening Station
