PF 1210 Impact Crusher with Low Product Stone Powder

Name: PF 1210 Impact Crusher with Low Product Stone Powder
Brand: Henan Hongxing Mining Machinery Co., Ltd.
Availability: InStock

Large Image : PF 1210 Impact Crusher with Low Product Stone Powder

Product Details:

Contact Now

Detailed Product Description

Product Description

PF series impact crusher

PF series impact crusher integrates the current domestic and international new technology and combines with the working conditions of sand and gravel industry to refine the rotor and crushing cavity for different fields of application. We use new high wear-resistant materials to greatly improve equipment performance and throughput. It is a kind of very important mining crushing equipment. The size of the discharge size can be adjusted, and the crushing specifications are diversified.

Unique structural design and advanced manufacturing technology has been adopted on this crusher design. The impact crushers are widely used in the crushing of low-abrasive materials with medium hardness and below such as railways, high ways, energy, building
materials, chemical industries and other industries.

Application fields

Limestone, river pebble, coal gangue, granite, cobble, dolomite, bluestone, iron ore, construction waste, glass, cement clinker, etc.

Product Structure

Structural features

A) The triple countermeasure plate structure increases the hammer head loss, reduces hard extrusion and hardness, reduces hammer head loss, and extends the life of wear-resistant parts.

B) The gap between the impact plate and the hammer head can be easily adjusted by adjusting the bolts to effectively control the particle size of the discharge.
C) The PF1315 type cover is equipped with a hydraulic device to make maintenance more convenient.

Working Principle

Working principle

After the material enters, it hits the high-speed rotating head and is hit head-on by the hammer. The large pieces of material are immediately broken, and the broken materials fly to the impact plate at high speed for the second hammer collision and crushing. The rebound and the subsequent flying transactions are interrelated and destroyed to achieve the final destruction purpose.

Equipment Advantage

Equipment advantage

A) High efficiency and energy-saving

Big feeding inlet and high crushing chamber, which are applicable for large—lump hard materials with low powder rate.
B) Fantastic particle type
The interval between impact plate and hammer can be easily adjusted, which effectively control the discharging size to simplify the crushing circuit and ensure good cubic particle shape.
C) Unique structure
Simple Compact structure; keyless connection; strong rigidity; the rotor has a large moment of inertia.
D) High comprehensive efficiency
High chromium hammer and special impact liner plate, resistance to wear, large impact force, easy maintenance, reliable performance.

Technical Parameter

Technical Parameter of Impact Crusher

Model	Specifications (mm)	Feed Opening Size (mm)	Max Feeding Size (mm)	Capacity (t/h)	Weight (t)
PF-1007	φ1000*700	400*730	300	30-70	12
PF-1010	φ1000*1050	400*1080	350	50-90	15
PF-1210	φ1250*1050	400*1080	350	70-130	17.7
PF-1214	φ1250*1400	400*1430	350	100-180	22.4
PF-1315	φ1320*1500	860*1520	500	130-250	27
PF-1320	φ1300*2000	993*2000	500	165-320	34
PF-1520	φ1500*2000	830*2040	700	300-500	50
PF-1820	φ1800*2000	1260*2040	800	600-800	83

Packing & Delivery

Packaging & Delivery of Mining Equipment

1.The motor will be packed in wooden case

2. Main machine nude packing in Container / Flat Rack

3. Delivery time :10-15 days

Customer site

Whole crushing plant site pictures:(feeder+jaw crusher+impact crusher+screen etc)

Customers from different countries:

Customer from Sudan

Customer from India

Customer from Bahrain

Our Company

Henan Hongxing Mining Machinery Co., Ltd. is a joint-stock mining machinery manufacturing enterprise integrated in scientific research, production and marketing. Our company is located at the Zhengzhou High & New Technology Industries Development zone with an area of 50 thousand square meters which includes 15,000sqm of standard heavy industrial workshop. Equipments include large and medium sized metal processing, riveting and installing equipments are more than 160 pieces. There are more than 660 workers including 80 administrators with secondary and senior occupational titles and engineering technicians. In order to promote the competitive strength, our company have introduced the advanced technology from America, Germany, Japan and Australia, which established the international advanced production line, first-class modern testing base as well as research centers of sand maker,
mill and mine-selecting equipment. With the scientific management advanced processing technology and innovative manufacturing theory, our company became the first level one of the mining machinery manufacturing and exporting base in China. Hongxing Company lays much emphasis on the quality and clients. We serve clients with the quality guideline of being responsible for every working procedure, every product and every client. What we have done is for the clients and we believe that quality is the best way to develop market. All of the products have passed the authentication of ISO9001. Hongxing Brand is the Chinese Famous Brand. Reliable and stable quality is the key to success. Our products are well known at home and abroad. Now we have tens of thousands of users throughout China and more than 30 world markets. The leading products in our company include: ball mill, Raymond mill, sand-maker, jaw crusher, hammer crusher, vertical compound crusher, rotary kiln, drier, vibrating screen, sand maker, magnetic separator, SF flotation machine, roll crusher, belt conveyor, bucket elevator, spiral classifier, impact crusher, granulating disc, final screen, lift mixer, table concentrator, centrifugal ore separator, high-efficiency concentrator, disc feeder, pendulum type feeder and hydraulic cyclone. Moreover, we can provide program design, process flow design, standard and non-standard design for clients. The persistent operating theory of Hongxing is: the development way depends on the concept and the good product comes out of the good faith. We have been awarded the "Civilized Enterprise" "Key Enterprise" "Enterprise with Standard Quality" and
"Enterprise with Honesty and Credit Standing". We firmly believe that we can get sincere repayment with our sincere dedication.
