CJ Series CJ200 Jaw Crusher Stone Crusher

Name: CJ Series CJ200 Jaw Crusher Stone Crusher
Brand: Henan Hongxing Mining Machinery Co., Ltd.
Availability: InStock

Large Image : CJ Series CJ200 Jaw Crusher Stone Crusher

Product Details:

Contact Now

Detailed Product Description

Product Description

Brief Introduction of The Production

The Jaw crusher is used as Primary and Secondary crushers for crushing all kinds of minerals and rocks with compressive strength less than 320 Mpa.
There are two types of Jaw crusher: coarse jaw crusher and fine jaw crusher. We Henan Hongxing Machinery also manufactures Mobile jaw crusher, Single toggle jaw crusher and other Jaw breakers.

Jaw crushers machine are invented in 1858 and first widely applied in road paving and then in mines. As one kind of small jaw crusher, it has many particular characteristics such as high crushing ratio, even product granularity, simple structure, reliable working condition, convenient maintenance and economical operation cost. The small jaw crusher also called pe jaw crusher in the mining industry. PE jaw crusher machine has the same advantages with stone crusher.

Technical parameters

Working Principle

The engine starts running, turning the belt and pulley, and moving the jaw up and down. When the movable jaw rises, the Angle between the bracket and the movable jaw increases so as to push the movable jaw towards the fixed jaw, and at the same time the material is crushed or split to achieve the purpose of crushing. When the movable jaw descends, the Angle between the bracket and the movable jaw becomes smaller, and the movable jaw leaves the fixed jaw under the action of pull rod and spring. At this time, the material that has reached the crushing granularity requirement of the user will pass through the discharge port and be sent to the finished product warehouse along with the belt conveyor. With the continuous rotation of the motor, the moving jaw moves periodically, and the material is crushed by the components to realize mass production.

Part of Product

pulley

propeller Shaft

flywheel belt pulley

manual grease station motor

gnathochilarium spring

conditioner lubricating system

Packing & Delivery

Working Site

Our factory

Hongxing is a large-scale joint-stock enterprise mainly engaged in the production of heavy mining machinery and integrating scientific research,production and sales together.It currently has three large-scale production bases. The company headquarter is located in Zhengzhou High-tech Industrial Development Zone,with a total of area of 350,000 square meters,260,000 square meters of standardized heavy industrial workshop,and more than 600 advanced production and processing equipment.There are more than 2,300 online employees,including more than 3600 management cadres and engineering technician with middle and senior titles.
Hongxing built an internationally advanced production line and a first-class modern testing base,establishing a sand and stone machine research institute,a milling machine research institute,a mineral processing equipment research institute and a building material equipment research institute.All the products have passed the ISO9001,CE and GOST international quality system certification.
Its reliable and stable quality makes the company's production and sales volume and various comprehensive economic indicators steps into the forefront of the domestic industry,tens of thousands of users all over the country and exported to more than 100 countries.
