China HongXing Hot Sale HDX98 110-410t/h Geramn Type Jaw Crusher

Name: China HongXing Hot Sale HDX98 110-410t/h Geramn Type Jaw Crusher
Brand: Henan Hongxing Mining Machinery Co., Ltd.
Availability: InStock

Large Image : China HongXing Hot Sale HDX98 110-410t/h Geramn Type Jaw Crusher

Product Details:

Contact Now

Detailed Product Description

Equipment Introduction

HDX Series Geramn Type Jaw Crusher.

The HDX german type jaw crusher is an upgraded product based on the HD German type jaw crusher based on the combination of many customer sites and market needs. It saves space, easy to operate, and reduces the cost of infrastructure construction, installation, operation and maintenance.

Equipment Advantage

Integral Motor Frame.

The integral motor frame makes the installation easier; reduces the installation space; The crusher moves synchronously with the integral motor main shaft, which improves the load on the V-belt.

Wedge Adjustment.

There are two adjustment methods: mechanical and hydraulic. The discharge opening can be adjusted within a few minutes, which greatly reduces labor intensity and downtime; this system is especially effective to clean the cavity.

The Damping Device

The use of rubber shock absorbers and limit blocks can absorb peak vibration loads and allow the crusher to move horizontally and longitudinally, thereby effectively reducing the impact of the crusher on the foundation and avoiding the damage to the foundation by the anchor bolts.

Steel Toggle Plate.

The steel toggle plate is light in weight, easy to replace, and bends when exceeded, avoiding damage to the conveyor belt when the traditional cast iron toggle plate breaks and falls.

Technical Parameter

Model	Feeding opening(mm)	Adjust range of discharge opening(mm)	Processing capacity(mm)	Power(kw)	Dimenssions(LWH)(mm)
HDX72(57)	720*460	45-100	50-120	6P 55	245021601615
HDX86(69)	860*580	50-150	60-280	8P 75	300523921780
HDX98(751)	980*680	75-175	110-410	8P 110	337225302145
HDX110(912)	1100*850	100-200	170-550	6P 132	359226702515
HDX125	1250*950	125-225	280-750	8P 160	421428102887

Note.

Product pictures and parameters about models, data, performances and specifications on this website are for reference only. There is a chance that HongXing may make changes on above-mentioned information. For specific messages, please refer to the real objects and user manuals. Without special instructions, HongXing keeps the right to explain all data involved in this website.

Company Introduction

About HongXing.

Hongxing Group is a comprehensive large scale joint stock enterprise integrating scientific research, production, sales and after sales. Formerly known as the 55201 Machine Factory of the Chinese People's Liberation Army, it was a military enterprise and an important enterprise of "high-tech" scientific research and technology development in China at that time, with a strong technical background.The existing R&D,management, production and marketing staff of more than 2,300 people, four modern production bases covering an area of 350,000 square meters, is a national high tech enterprise and domestic high-e mining machine production and export base. The Group focuses on mining machine manufacturing, covering four series crushing sand making, screening and grinding, while providing customers with engineering design and EPC general contracting services, adhering to the "one enterprise, one policy" tailor-made ore processing solutions

Factory Introduction

Four production bases

For more than 40 years, the Group has never forgotten t he original intention of creating a Chinese industrial brand and creating a world class mining machine, always adhering to the mission of creating greater value for customers, continuously improving scientific research investment in the development of new products, optimizing and upgrading project solutions, and making unremitting efforts to improve the production and operation income of customers. Products have passed ISO9001, CE (European Union), GOST (Russia) and other international quality system certification. Forever first-class Hongxing Machinery provides services to tens of thousands of mining enterprises around the world and has been universally praised.

Customer Photos and Company Honor

Since its establishment, Hongxing group lays much emphasis on the quality and clients, regards quality as its life and respects users as God, and has always followed the quality policy of being responsible for each process, being responsible for each product, and being responsible for each user, and dedicated to serving users w wholeheartedly. Aiming at the forefront contemporary technology,Hongxing continuously develops, introduce new products,an ad strives to strive for a first-class level in management, scientific research,technology, etc. Now all the company's products have passed ISO9001, CE and GOST international quality system certification. “Hongxing brand machine” has won "China's famous brand" and "China's top ten brands of mining machinery"and many other awards. Hongxing occupies the market with poroducts, creates the market with services, and leads the market with brands."Building a Hongxing brand and satisfying users" is the e eternal pursuit of Hongxing group.

Our service

Packaging & Shipping

Ways of Packing: 1.Sand blasting, coat with high quality paint; 2.Product wrap by PP-Bubble 3.Load container, Spear Parts in wooden case.

Transportation: 1. By sea Freight; 2. MSK/MSC/APL/EMC/WANHAI/KLINE 3. We will remind you before boat arrival

FAQ.

To choose a suitable model , we need to know : 1. what kind of stone do you want to crush ? limestone ? granite ? river stone ? or ? 2. what's the size of your stone before crush ? how many mm or inch ? 3. what's your requirement of production capacity ? how many ton per hour? 4. what's your requirements of final products size ? Q: what is the payment terms ? A: 30% prepayment by T/T , after the seller finish the production process and buyer verify the machine , 70% balance should paid before delivery, L/C is also acceptable . Q: what's the delivery time ? A: Most model is in stock, delivery time within 7 days after buyer got the payment Q: How long will the shipment takes ? (roughly ) Africa : 30-45 days Asia : 5-25 days America : 15-40 days Europe : 30-40 days Q: Which airport and train station is near to the factory ? A: Zhengzhou xinzheng international airport and Zhengzhoudong Railway Station Welcome to inquiry
